battery tester
1. Overview
The BHT3554 battery tester measures internal resistance, voltage, and terminal temperature of lead-acid, nickel-cadmium, nickel-hydrogen, and other types of batteries, enabling you to determine if the battery is worn out. The measurement data can be copied to a computer by connecting the instrument to a computer after measurement with the USB cable provided.
2. Features
Enables measurement without shutting down UPS systems;
Reliable measurement values;
Simultaneous display of resistance, voltage, and temperature;
The comparator function enables you to set threshold values for internal resistance and voltage. This can determine battery wear more easily;
Large memory capacity, storing up to 2400 sets of data combining presently measured values (resistance, voltage, temperature, and comparator measurement results). It can be used to measure up to 12 units of 200-cell cubicles;
Auto-memory function;
Measurement data can be loaded into a computer;
Small size: The instrument has a similar size with A5 paper, easy to carry;
Remote Control Switch (optional) for storing measurement values.
